Sun Fire[tm] V245 Server
Sun V245
Racking |Processors | Main Memory | Standard Interfaces | Internal Mass Storage
Environment | Regulations | Dimensions and Weight
Processor Options
top |
Processor: One or two 1.5 GHz UltraSPARC IIIi
Architecture: 64-bit, 4-way superscalar SPARC V9
Cache: 64 KB data, 32 KB instruction and 1 MB integrated L2 cache
|
Main Memory
top |
Main Memory: 4 DIMM slots per processor, registered DDR-1 SDRAM (PC2700) 128 bit + ECC databus system configurations from 1 GB to 16 GB
X8711A - Sun Microsystems 4GB(2 X 2GB DDR333 /PC2700 ECC DIMM)Memory FRU, RoHS;Y
X8704A - Sun 2GB Memory Expansion Kit (2*1GB) low-profile DDR1 PC2700 ECC
DIMMs
X8703A - Sun 1-GB Memory Expansion Kit (2 X 512MB) low-profile DDR1 PC2700
ECC DIMMs
|
Standard/Integrated Interfaces
top |
Network: Four 10/100/1000Base-T Ethernet
Network Management: One 10/100Base-T Ethernet
Serial Management: One TIA/EIA-232-F (RJ45) port
Serial Port: One asynchronous (RJ45) serial communications port
USB: Two USB 1.1 ports supporting speeds of 12 Mbps and two USB 2.0 ports supporting
speeds of 480 Mbps
Expansion Bus: Two PCI-X 133 MHz/64-bit full height slots; one full-length and one short
slot.
Two PCIe low-profile/short slots with 16-way connector; one x8 lane and one x4 lane
System Cofigurations: Socketed Systems Configuration Chip contains system ID
SG-XPCI8SAS-E-Z - Sun Microsystems PCI-X 3GB/s 8-Port Host Adapter
SG-XPCIE8SAS-E-Z - Sun Microsystems PCI-E 8-Port Host Adapter
X7280A-2 - Sun PCI Express Dual Gigabit Ethernet UTP
X7281A-2 - Sun Microsystems PCI Express Dual Gigabit Ethernet MMF
|
Mass Storage and Media
top |
Internal DIsk:
Up to four hot-plug 73 GB 2.5-inch SAS disks, 146 GB optional
Internal DVD : One slimline ATAPI DVD-Dual drive
External Disk:
- Sun StorageTek 3120 SCSI Array
- Sun StorageTek 3310 SCSI RAID/JBOD Array
- Sun StorageTek 3320 Array
- Sun StorageTek 3510 FC RAID/JBOD Array
- Sun StorageTek 3511 FC array with SATA RAID/JBOD Array
- Sun StorageTek 5310 Array
- Sun StorageTek 99xx series (approval pending)
- Sun StorageTek 6130 with Management Software Unity 3.1
- Sun StorageTek 6140 Array
- Sun StorageTek 6540 Array
- Sun StorageTek 6920 Array
External Tape:
- Sun StorageTek DAT 72 tape drives,USB and SCSI, desktop and rackmount
- Sun StorageTek LTO 2 half-height tape drives, desktop and rackmount
- Sun StorageTek LTO 3 tape drive,desktop and rackmount
- Sun StorageTek SDLT 600 tape drive, desktop and rackmount
- Sun StorageTek L8 tape autoloader SDLT320 and LT0 2
- Sun StorageTek L25 with LT0 2
- Sun StorageTek L100 with LT0 2
- Sun StorageTek L500 with LTO 2,LTO 3 and SDLT 600 drives
- Sun StorageTek C2 autoloader with LTO 2 HH, LTO 3 and SDLT 600 drives
- Sun StorageTek C4 with LTO 2, LTO 3 and SDLT 600 drives
- Sun StorageTek C4 Native FC with LTO 3 and SDLT 600 drives
- FC bridge card for Sun StorageTek C4 with LTO 2, LTO 3, and SDLT 600 drives
XRB-SS2CD-146G10KZ - Sun 146GB 10000 RPM Serial attached SCSI (SAS) Disk, RoHS:Y
XRA-SS2CD-146G10KZ - Sun 146GB 10000 RPM SAS Disk Drive
XRB-SS2CD-73G10KZ - Sun Microsystems73GB 10000 RPM SAS Disk Assembly with 1 bracket and 1disk, RoHS:Y
XRA-SS2CD-73G10KZ - Sun 73.4GB 2.5-inch 10K RPM 3Gb/Sec Serial Attached SCSI (SAS) Disk Drive
|
Software
top
|
Operating System: Solaris 10 OS beginning with 06/06
Solaris 9 OS beginning with 09/05 HW
Languages: C/C++, FORTRAN, Sun Java programming language; all other standard Sun-supported
languages
Networking: ONC, NFS, TCP/IP, SunLink, OSI, MHS, IPX/SPX
Management:
Sun Management Center, Sun SNMP Management Agent, Advanced Lights Out Management
(ALOM), Sun Net Connect and Sun Update Connection
Sun Java Enterprise System: Studio 11 software (pre-installed)
Sun Java Enterprise System Release 4 (pre-installed)
|
Power Supplies
top |
Redundancy: One required, two for redundancy (hot-swappable)
Maximum DC output: 400 W
AC Power: 90 - 264 V AC (47 - 63 Hz)
X8428A-Z - Sun Microsystems AC Power Supply
|
Environment
top |
Operating Temperature: 5° C to 40° C (41° F to 104° F), Temperature 10% to 90% relative humidity, non-condensing, 27° C max. wet bulb
Non-Operating Temperature: -40°C to 65°C (-40°F to 149°F), up to 93% relative humidity, non-condensing, 38°C max wet bulb
Operating Altitude: Up to 3,000 m, maximum ambient temperature is derated by 1° C per 500 m above 500 m
Non-Operating Altitude: Up to 12,000 m
Acoustic Noise: Less than 7.1B sound power in ambient temperature of up to 24° C
|
Regulations(meets or exceeds the following requirements)
top |
Safety: IEC60950, UL/CSA60950, EN60950
RFI/EMI: FCC Class A, Part 15 47 CFR, EN55022, CISPR 22
Immunity: EN55024
Certifications - Safety: cULus Mark, TUV GS Mark, CE Mark, S-Mark, CCC, GOST
Certifications - EMC: CE Mark (93/68/EEC), FCC authorized Class A, ICES, VCCI, BSMI, CTICK, MIC, CCC,
GOST
RoHS: RoHS-compliant with lead-in solder exemption |
Dimensions and Weights
top |
Chassis: Height: 87.9 mm (3.4 inches)
Weight: 457 mm (18 inches)
Depth: 609.6 mm (24 inches)
Weight: 19 kg (41.8 lb.) fully configured; 22.4 kg (49.31 lb.) with rackmount rails and
cable management arm
Enclosure: Fits into a standard 19-inch wide rack. Four-post rack kit adjustable between
720 mm and 925 mm
|
245-ELZ2C12GC2
